SPECIFICATIONS
KI9600WS01-Ge
Calibrated wavelengths(nm)
1550
Measurement of 1550nm
Pass band
Isolation of 1490nm band
Isolation of 1310nm band
Max permitted input level
Measurement range
1530 to 1625
> 25dB
> 30dB
+15dBm
+10 to -70 dBm
Measurement accuracy
Midrange linearity¹
Polarization sensitivity
0.04 dB
< 0.005 dB
Total Uncertainty³
0.5 dB
KI 9600XL Series Large Area Optical Power Meter
Detector type
Response

nm
Damage
level
dBm
Calibration 
nm
Power
range
dBm
Midrange
linearity¹
dB
Calibration
Accuracy
2
%
Polarisation
Sensitivity
dB
Total
Uncertainty³
dB

Sensitivity
5
± 30 nm
dB
5mm Ge
600 ~ 1650
+15
635,650,660,780,1610,1625
850,1300,1310,1390,1490,1550
+10 ~ -35
+10 ~ -40
0.04
2 %
< 0.005
0.5
0.04
5 mm Si
350 ~ 1100
+10
470, 520,
635, 650, 660,
780, 850, 980
+5 ~ -50
+5 ~ -60
0.02
2 %
< 0.005
0.3
0. 03
typical
typical
max
typical
Note 1: Midrange linearity excludes top 3 dB and bottom 10 dB of range.
Note 2: Calibration condition: non coherent light, -35 ± 5 dBm, 23 ± 1
°
C, ± 1 nm, 10 ± 3 nm FWHM, PC ceramic connector, 100 µm fiber.
Note 3: Includes contributions of: varying optical connector types, calibration uncertainty, linearity over temperature & range, and fiber core diameter up to 200µm.
Note 5: At calibration wavelengths in bold type.
