PARTS LIST
Prior to assembly, check all parts against the parts list. Carry out assembly on a soft surface to avoid scratching
the paint. For ease of assembly, only loosely tighten bolts and then tighten fully when assembly is complete.
WARNING: Do not over-tighten bolts. Only tighten all bolts with moderate pressure to avoid damaging the bolts
or components of the ceramic charcoal barbecue.
IMPORTANT: Remove all packaging before use, but retain the safety instructions and store them with this product.
Ensure that the lid is closed prior to assembly.
ID Part name QTY Part image
A Bolt (18” / 21” / 24”) 16
B Screwdriver (18” / 21” / 24”) 1
1 Support bracket (18” / 21” / 24”) 4
2 Locking caster wheel (18” / 21” / 24”) 2
3 Caster wheel (18” / 21” / 24”) 2
4 Bracket crosspiece (18” / 21” / 24”) 2
5 Main cooking grid 1
6 Charcoal plate 1
7 Firebox 1
8 Ceramic body 1
9 Top damper vent 1
10 Lid handle 1
11 Side shelf 2
12 Side shelf brackets 4
