KINKI STUDIO
11
The EX-M7 is equipped with EARTH/GND optimization
scheme where you may utilize it to optimize the sonic
performance of the system.
Tog gle the LINK/FLOAT switch (3) to engage or dis-engage
the power earth (2) with the chassis (1).
You may connect the EARTH (4) and/or GND (5) to the
upstream equipment to link the amplifier chassis to the
upstream equipment chassis. If the upstream equipment
does not come with a GND terminal, you may attach the
wire to the screw.
You may connect the EARTH/GND terminal to the ground
box too to experiment the differences. Enjoy!
1 2
3 4
5
