KINROAD 150 SERVICE MANUAL VERSION 1, DEC., 2005
17
Use special tools to remove the starting driven gear.
Remove the crankcase positioning bolts.
Separate the right crankcase and the left crankcase.
Remove the gasket and the dowel pins.
Remove the crankshaft from the crankcase.
Take out the cam chain.
Clean up the gasket on the crankcase joint face. Pay attention not to
damage the joint face.
Remove the oil seal from the left crankcase.
The joint face cannot be damaged.
