KINROAD 150 SERVICE MANUAL VERSION 1, DEC., 2005
56
TRANSMISSION BELT
TRANSMISSION BELT INSPECTION
Remove the left crankcase cover.
Inspect if the transmission belt is chapped or worn.
Measure the width of the belt.
Service limit 19.0mm
Replace the belt if its width is less than the above limitation.
See the drive pulley removal and installation procedure for the replacement.
z When replacing, you must use the OEM part for correct fit.
