KINROAD 150 SERVICE MANUAL VERSION 1, DEC., 2005
60
Remove the sub-shaft bearing.
Drive in the new final gear shaft and bearing.
Drive in the new sub-shaft bearing.
Drive in the driven pulley shaft bearing.
BEARING ON THE LEFT CRANCASE BODY REPLACEMENT
Inspect if the bearing and oil seal on the left crankcase for wear or
damage. If it is damaged, it must be replaced.
Remove the oil seal.
Drive out the final gear shaft bearing.
z When driving in the final gear shaft bearing, keep the
bearing parallel. The same is required when installing the
sub-shaft bearing and the driven pulley shaft bearing.
z When removing or installing the bearing on the left crankcase body, you must use the special tool.
