KINROAD 150 SERVICE MANUAL VERSION 1, DEC., 2005
62
Install the driven belt pulley shaft on the transmission case cover.
Drive in the transmission case cover oil seal.
Mount the sub-shaft/sub-shaft gear and the final gear shaft into the
left crankcase.
Mount the final gear on the final gear shaft.
Install the new dowel pin and gasket.
To Next Page
