5
-28 EX35/40/45/50
PARKING BRAKE LEVER
(1) Parking Brake Lever
(2) Brake Pedals (3) Interlock
(A) DEPRESS (B) PUSH “DOWN”
PARKING
To avoid personal injury:
Always set the parking brake
and stop the engine before leav-
ing the tractor seat.
When parking the vehicle on a
hill, position the shift lever in
low forward (1st gear) for uphill
and low reverse (1st gear) for
downhill. Set the parking brake
and chock the wheels.
!!
!!
!
CAUTION
T46O580A
HST TYPE
Leaving transmission in gear
with the engine stopped will not
prevent tractor from rolling.
Park on level ground whenever
possible.
!!
!!
!
CAUTION
HST Type
MANUAL Type
If the range shift is at high speed, this
lamp turned in green(HST).
T46O579A
Always lock the parking brake.
“H” HIGH SPEED TRAVEL
INDICATOR
