-4 EX35/40/45/50
REAR WHEELS
(A) Tread
EX35
Model
-
1,221
(48.1)
Farm Turf Industrial
-
1,304
(51.3)
EX40
EX45
EX50
1,206
(47.5)
1,304
(51.3)
mm(in.)
-
1,290
(50.8)
1,278
(50.3)
1,237
(48.7)
1,380
(54.3)
1,380
(54.3)
1,348
(53.1)
1,490
(58.7)
1,478
(58.2)
1,301
(51.2)
1,415
(55.7)
1,513
(59.6)
1,318
(51.9)
1,370
(53.9)
1,370
(53.9)
EX35
EX40
EX45/50
12.4-24 / 6PR
13.6-24 / 6PR
13.6-26 / 6PR
Model
Tire size
Farm Turf Industrial
41-14-20 / 4PR
41-14-20 / 4PR
21.5L-16.1 / 4PR
43-16-20 / 4PR
14.9-24 / 6PR
17.5L-24 / 8PR
T46O802A
Always attach tires as shown in the drawings.
If not attached as illustrated, transmission parts may be damaged.
When re-fitting or adjusting a wheel, tighten the bolts to the following
torques then recheck after driving the tractor 200 m (218 yards) and
thereafter according to service interval.
Torques : 166 N·m (23 kgf·m, 226 lbf·ft)
IMPORTANT
