SPECIFICATIONS
IMPLEMENT LIMITATIONS
This KIOTI tractor has been thoroughly tested for proper performance with implements approved by KIOTI. Use with
implements which are approved by KIOTI and which exceed the maximum specifications listed below, or which are other-
wise unfit for use with this KIOTI tractor may result in malfunctions or failures of the tractor, damage to other property and
injury to the operator or others. [Any malfunctions or failures of the tractor resulting from use with improper implements are
not covered by the warranty.]
NOTE : Implement size may vary depending on soil types and field conditions.
Front
Tread (max. width)
Rear
Lifting Capacity max. loading weight .......... The max. allowable load which can be put on the 24 in. aft of hitch : W
0
Implement weight ....................................... The implement's weight which can be put on the lower link : W
1
Max. drawbar load ...................................... W
2
Trailer loading weight .................................. The max. loading weight for trailer (without trailer's weight) : W
3
Model
Item
Implement weight W
1
and / or size
Actual figures
Max. Drawbar Load W
2
Model
Item
650 kg
(1433.0 lbs.)
1,248 mm (49.1 in)
1,245 mm (49.0 in)
1,365 mm (53.7 in)
1,348 mm (53.1 in)
1,490 mm (58.7 in)
1,515 mm (59.6 in)
As in the following list
(Shown in the next page)
Lifting Capacity max.
loading weight
(24 in. aft of hitch)
T46O301A
Trailer loading weight
W
3
Max. capacity
3,500 Kg
(7716.1 lbs.)
EX35
EX40
EX45/50
EX35
EX40
EX45/50
1,081 Kg (2,383 lbs. )
1,131 Kg (2,493 lbs.)
