Kioti EX45 - SELECTING THE TRAVEL SPEED (MANUAL Type)

5 -16 EX35/40/45/50
T46O562A
(1) Forward/Reverse Shift Lever
(2) Main Gear Shift Lever
(3) Creep Gear Shift Lever
(4) Range Gear Shift Lever(Hi-Mid-Lo
)
MANUAL Type
(1) FORWARD/REVERSE SHIFT LEVER
Push forward or pull backward to se-
lect forward or reverse. The direction
of travel can be changed without chang-
ing the main shift.
(2)MAIN GEAR SHIFT LEVER
4 level shifts are possible with one
lever. Synchro-mesh type. Just release
the clutch during driving to change the
speed.
 The synchronized shuttle shift
lever may be shifted while the
tractor is moving slowly and the
clutch is depressed.
 Sudden gear shift changes with-
out clutching may cause trans-
mission damage.
IMPORTANT
6. SELECTING THE TRAVEL SPEED
(MANUAL Type)
N -"NEUTRAL POSITION"
- "HIGH"
-"MIDDLE"
-"LOW"
F -"FORWARD"
R - "REVERSE”
 Shifting the shuttle & high
speeds without slowing down
may cause premature synchro-
nizer wear
