Kioti EX45 - INSTRUMENT CLUSTER

5 -23 OPERATION
If warning lamps come on while oper-
ating the engine, immediately stop the
engine and check for the cause.
Never operate the tractor while warn-
ing lamps are on.
INSTRUMENT CLUSTER
(1) PTO Operating Indicator
(2) Headlight-High Beam Lamp
(3) Battery Charging Warning Lamp
(4) Parking Brake Lamp
(5) Cruise Operating Indicator
(6) Glow Plug Indicator
(7) Left Turn Indicator
(8) Tachometer
(9) Right Turn Indicator
(10) Neutral Position
(11) Engine Oil Pressure Warning Lamp
(12) Single Brake Lamp
(13) Front Wheel Drive Indicator
(14) Fuel Gauge
(15) Hour-Meter Indicator
(16) Coolant Temperature Gauge
T46O566A
