5150
OPTIONAL ACCESSORIES
Hard Floor Pad
For additional floor protection from possible scratches, the
optional Hard Floor Pad can be used when vacuuming bare
floors.
For use on dry floors only.
1
Turn the unit off. Step on the bottom pedal of the Toe-Touch
Control to raise the Power Nozzle. Slide the Hard Floor Pad
under the nozzle and press up until the clips lock in place.
Turn unit off, unplug power cord from wall outlet, and be
sure the motor and nozzle brush have stopped before
attaching the Hard Floor Pad.
2
Turn the Belt Lifter counterclockwise until the red arrows line
up to convert the unit to a straight suction cleaner.
3
Put Tech Drive® power assist in neutral. Lower the Power
Nozzle and vacuum the floor.
4
To remove the Hard Floor Pad, raise the Power Nozzle and
step down on the tabs at the back of the Hard Floor Pad.
