KIRLOSKAR DB 80/16 User Manual

18
This is a proprietary document of Kirloskar Brothers Limited, Kirloskarvadi-416308, Dist-Sangli (India)
ISSUE DATE: 17.09.2010 LAST REV. DATE:
Part No. Description Qty. per pump
457 Vent plug 1
600 Gauge plug 2
601 Drain plug for casing 1
602 Sealing plug 1/2
605 Drain plug for bearing housing 1
517.1 Gasket for collared plug 1
517.2 Gasket for collared plug 1
517.4 Gasket for st. box sealing plug 1/2
517.2 Gasket for suc. gauge plug 1
513.3 Gasket for brg. housing drain plug 1
610.1 Locking pin for casing wear ring 1/2
656 Screw for sealing hole (for external sealing
pumps) 1
* Recommended spares for two-year normal working.
- Recommended spares for five-year normal working.
