KIRLOSKAR HA 494T User Manual

19
1. Fuel tank
2. Fuel pipe - tank to fuel pump
3. Fuel feed pump
4. Fuel filter
5. Injection pump
6. Fuel injection pipe
7. Fuel Injector
8. Leak-off pipe
9. Fuel overflow line
10. Overflow valve
11. Fuel return line to tank
A. Clearance; keep as far apart as
possible. (Min. 200mm)
2.4 Fuel System 2. Engine Description
2.4.1. Fuel System
7
6
5
3
4
2
11
1
10
8
9
