Attach a Red wire to the 5V terminal on
the Booster. Attach a Black wire to the
GND terminal on the Booster.
Attach the Red and Black wires from the
Booster to the Bluetooth board. Black
wire to the GND terminal, Red wire to
the +5V terminal.
Bluetooth Speaker Kit Instructions V.2
