KitchenAid 720-0953A (LP) - Page 100

100
No. Part (Description)
Warranty
coverage
(year)
QTY No. Part (Description)
Warranty
coverage
(year)
QTY
1
Main lid 1 1 41 Side burner igniter wire 1 1
2
Main lid screw 1 2 42 Side burner bowl assembly 1 1
3
Main lid handle assembly 1 1 43 Side burner control panel 3 1
4
Temperature gauge housing 1 1 44 Grease box bracket 1 2
5
Temperature gauge 1 1 45 Tank heat shield panel 1 1
6
Side shelf, left 1 1 46 Grease box 1 1
7
Side shelf end cap 1 1 47 Cart frame, front 1 1
8
Hooks 1 6 48 Triangle bracket, left 1 1
9
Side shelf front panel, left 3 1 49 Door Magnet 1 2
10
Warming rack 1 1 50 Triangle bracket, right 1 1
11
Cooking grid with hole 3 3 51 Door, left 1 1
12
Flame tamer 3 3 52 Door handle assembly 1 2
13
Burner pin assembly 1 3 53 Door, right 1 1
14
Main burner 10 3 54 Door hinge 1 4
15
Main burner igniter wire A 1 1 55 Lighting rod 1 1
16
Main burner igniter wire B 1 1 56 Lighting rod cover 1 1
17
Main burner igniter wire C 1 1 57 Door iron piece 1 1
18
Main burner bowl assembly Non-replaceable 1 58 Swivel caster 1 1
19
Main lid bracket, right 1 1 59 Door hinge bracket 1 4
20
Main lid bracket, left 1 1 60 Side panel, left 1 1
21
Front baffle 1 1 61 Swivel caster with brake 1 1
22
Main gas valve 1 3 62 Tank bolt 1 1
23
Igniter junction wire 1 1 63 Back panel, bottom 1 1
24
Main manifold 1 1 64 Gas inlet rubber ring 1 1
25
Side burner flex gas line A 1 1 65 Back panel, top 1 1
26
LP regulator with Hose 1 1 66 Bottom panel 1 1
27
Side burner flex gas line B 1 1 67 Caster 1 2
28
Side burner gas valve 1 1 68 Side panel, right 1 1
29
Side burner orifice brass connector 1 1 69 NG orifice pack 1 1
30
Electronic igniter module 1 1 69a side burner NG orifice 1 1
31
Main control panel 3 1 70 NG conversion kit Sold separately as set
32
Logo 1 1 70a NG Regulator assembly
Sold separately
with #70
1
33
Bezel 1 3 70b NG Gas Hose with Quick Connector assembly 1
34
Control knob 1 4 70c 6mm nut driver 1
35
Side burner lid 1 1 70d Hex wrench 1
36
Side burner cooking grid 3 1 70e 6mm wrench 1
37
Side burner 1 1 70f Flat washer 2
38
Side burner lid hinge rod 1 2 70g Truss Head Screw with lock 2
39
Side burner lid hinge rod pin 1 2 KD-assembly hardware pack 1 1
40
Side burner end cap 1 1 manual 1 1
