KitchenAid KFGU766VSS00 - Page 4

BURNER BOX, GAS VALVES, AND SWITCHES
4
For Models: KFGU766VSS00
(Stainless)
W10184100
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Rail, Burner
8286753 Left
8286728 Right
2 8287312 Pipe, Manifold
3 Valve, Gas Burner
8286916 LR
8286919 LF,RR
8286920 RF
8287058 Center Dual
4 Seal, Shaft
W10140571 Single
W10140577 Dual
5
W10153621 Rail, Center
6
W10141511 Plate, Center Brnr
8 8286858 Bracket, Mainfold
9 3196160 Screw
10 8286687 Harness & Switches
11 4455917 Bracket, Mounting
12 8286737 Tubing, Gas
Burner (RF)
13 8286735 Tubing, Gas
Burner (LF)
14 8286738 Tubing, Gas
Burner (RR)
15 8286736 Tubing, Gas
Burner (LR)
16 8286771 Shield, Heat
17 8286829 Module,Reignition
18 8286751 Burner Box
19 8287103 Insulation,
Reignition Module
20 8286739 Cover,Reignit.Mdl.
21
W10132345 Regulator,
Pressure
22 8287076 Valve,Solenoid
Lock
23 8287055 Bracket,Single Vlv
24 8287056 Bracket,Dual Vlv
25 8287057 Screw, Brkt Vlv
26 8286820 Orifice Hldr 6K LR
27
W10140569 Orifice Hldr 7K LF
28
W10140570 Orifice Hld 10K RR
29 8286822 Orifice Hld 12K RF
30 8286936 Orific Hld 20K Ctr
31 8286729 Pipe,Ext. Crown
32 8286730 Pipe,Int. Crown
34 8286690 Transformer
35 Electrode
8286722 LF
8286723 LR
8286724 RF
8286725 RR
36 8286863 Spring,Electrode
37 Gasket, Orifice
8286930 LR
8286931 LF,RR
8286932 RF
38 8286740 Cover Plate
39 Orifice (NG)
W10151348 LR
W10151350 LF
W10151347 RR
W10151346 RF
W10151349 CTR
