KitchenAid KODE500ESS Installation Instructions

11
Cutout Height is Between 50¹⁄₂" and 51¹⁄₈" (128.2 cm and
129.9 cm)
1. Using 2 or more people, place the oven on its back on a
covered surface.
2. Install a foot on the left rear spacer using a #8-18 x ³⁄₈" screw.
NOTE: Position the foot so the long side of the foot is facing
toward the top of the oven.
3. In the same manner, install a foot on the right rear of the oven.
4. Install a front foot on the left front spacer using a #8-18 x ³⁄₈"
screw.
NOTE: Position the foot so the long side of the foot is facing
toward the inside of the oven.
5. In the same manner, install a front foot on the right front of the
oven.
6. Using 2 or more people, place the oven in its upright position.
7. Go to the “Make Electrical Connection” section.
A. Spacer
B. Foot
C. #8-18 x
³⁄₈ " screw
A
B
C
A. Front foot
B. #8-18 x ³⁄₈ " screw
C. Spacer
A
B
C

KitchenAid KODE500ESS Specifications

General

Type	Double Oven
Fuel Type	Electric
Convection	Yes
Self-Cleaning	Yes
Control Type	Touchscreen
Color	Stainless Steel
Voltage	240 V
Brand	KitchenAid
Model	KODE500ESS
Installation Type	Built-In
Number of Ovens	2
Upper Oven Capacity	5.0 cu. ft.
Lower Oven Capacity	5.0 cu. ft.
Amperage	40 A
Warranty	1 Year Limited
Total Capacity	10.0 cu. ft.
