Ifcodespermitandaseparategroundwireisused,itis
recommendedthataqualifiedelectricalinstallerdeterminethat
thegroundpathisadequateandwiregaugeisinaccordance
withlocalcodes.
Donotuseanextensioncord.
Besurethattheelectricalconnectionandwiresizeareadequate
andinconformancewiththeNationalElectricalCode,ANSI/
NFPA70-latesteditionandalllocalcodesandordinances.
Acopyoftheabovecodestandardscanbeobtainedfrom:
NationalFireProtectionAssociation
OneBatterymarchPark
Quincy,MA02269
WARNING:Improperconnectionoftheequipment-grounding
conductorcanresultinariskofelectricshock.Checkwitha
qualifiedelectricianorservicetechnicianifyouareindoubtasto
whethertheapplianceisproperlygrounded.Donotmodifythe
powersupplycordplug.Ifitwillnotfittheoutlet,haveaproper
outletinstalledbyaqualifiedelectrician.
Thisrangeismanufacturedwiththeneutralterminalconnected
tothecabinet.Usea3-wire,ULlisted,40-amppowersupply
cord(pigtail);oriflocalcodesdonotpermitgroundthroughthe
neutral,usea4-wirepowersupplycordratedat250volts,
40ampsandinvestigatedforusewithranges.
ElectricalConnection
Toproperlyinstallyourrange,youmustdeterminethetypeof
electricalconnectionyouwillbeusingandfollowtheinstructions
providedforithere.
• Rangemustbeconnectedtotheproperelectricalvoltage
andfrequencyasspecifiedonthemodel/serialnumberrating
plate.Themodel/serialratingplateislocatedinsidetheoven
doorontheright-handsideovendoortrim.Refertothe
figuresinthe"ProductDimensions"sectionofthe"Location
Requirements"section.
Whena4-wireor3-wire,singlephase120/240volt,60Hz,
AConlyelectricalsupplyisavailable,a50-ampmaximum
circuitprotectionisrequired.Whena4-wireor3-wiresingle
phase120/208volt60Hz,AConlyelectricalsupplyis
available,a40-ampmaximumcircuitprotectionisrequired,
fusedonbothsidesoftheline.
• Atime-delayfuseorcircuitbreakerisrecommended.
Therangecanbeconnecteddirectlytothefuseddisconnect
(orcircuitbreakerbox)throughflexibleornonmetallic
sheathed,copperoraluminumcable.See"Electrical
Connection."
• Allow2to3ft(61.0cmto91.4cm)ofslackinthelinesothat
therangecanbemovedifservicingisevernecessary.
• AULlistedconduitconnectormustbeprovidedateachend
ofthepowersupplycable(attherangeandatthejunction
box).
• Wiresizesandconnectionsmustconformwiththeratingof
therange(40amps).
• Thewiringdiagramislocatedontheundersideofthestorage
drawerorbelowthewarmingdrawerinaclearplasticbag.
If connecting to a 4-wire system:
This range is manufactured with the ground connected to the
cabinet. The ground must be revised so the green ground wire of
the 4-wire power supply cord is connected to the cabinet. See
"Electrical Connection."
Grounding through the neutral conductor is prohibited for new
branch-circuit installations (1996 NEC); mobile homes; and
recreational vehicles, or an area where local codes prohibit
grounding through the neutral conductor.
When a 4-wire receptacle of NEMA Type 14-50R is used, a
matching UL listed, 4-wire, 250 volt, 40-amp, range power supply
cord (pigtail) must be used. This cord contains 4 copper
conductors with ring terminals or open-end spade terminals with
upturned ends, terminating in a NEMA Type 14-50R plug on the
supply end.
The fourth (grounding) conductor must be identified by a green or
green/yellow cover and the neutral conductor by a white cover.
Cord should be Type SRD or SRDT with a UL listed strain relief
and be at least 4 ft (1.22 m) long.
4-wire receptacle (14-50R)
The minimum conductor sized for the copper 4-wire power
cord are:
40-amp circuit
2 No.-8 conductors
1 No.-10 white neutral
1 No.-8 green grounding
If connecting to a 3-wire system:
Local codes may permit the use of a UL listed, 3-wire,
250 volt, 40-amp range power supply cord (pigtail). This cord
contains 3 copper conductors with ring terminals or open-end
spade terminals with upturned ends, terminating in a NEMA Type
10-50P plug on the supply end. Connectors on the appliance end
must be provided at the point the power supply cord enters the
appliance. This uses a 3-wire receptacle of NEMA Type 10-50R.
3-wire receptacle (10-50R)
