KITO EQ series User Manual

117
Appendix Electric, component and chain
A
Figure # Part Number
Part Name
Quantity per unit
Part Code
Remark
EQ001IS EQ003IS
EQ004IS
EQ005IS
EQ010IS
1 2104 Controller cover assembly 1 EQ1CI2104 ← ← EQ1DI2104
2 161 Socket bolt 4 J1BE1-0602525 ← ← ← For Controller cover
3 224 Toothed lock washer 4 J1WH012-10060 ← ← ← For Controller cover
4 800 Name plate B 1
EQ1BEE04I9A3 (490kg)
EQ1BUQ01I9A3 EQ1BUQ03I9A3 EQ1BUQ05I9A3 (500kg) EQ1BUQ10I9A3
5 866 Warning sticker E 1 E2DPX10S9866 ← ← ←
6 1571 Inverter assembly 1
INV60FY44 INV60FY41 INV615Y41 INV622Y41 400V class
INV60FC44 INV60FC41 INV615C41 INV622C41 230V class
7 508 HBB board 1 ECP91KB22 ← ← ←
8 191 Machine screw with spring washer 4/2 J1AP2-4001010 ← ← ←
For Inverter, 230V class
provides 2 pieces
9 1011 Bottom hook complete set 1
EQ1CI1035 (490kg)
EQ1CG1011 EQ1CF1011 EQ1CI1011 (500kg) EQ1CI1011
10 1002 Hook latch assembly 1 ER2CS9002 ← ← ER2DS1002
11 874 Load chain 1 KAZN056W0000 ← ← ←
12 054 Limiting plate 1 X X EQ1CI9054 EQ1DI9054
13 051 Chain spring 2 X X EQ1CI9051 EQ1DI9051
14 055 Spring guide 1 X X EQ1CI9055 EQ1DI9055
15 1041 Stopper assembly 2 ER1CS1041 ← ← ER1DS1041
16 1951 Lubricant tube assembly 1 ER2CS1951 ← ← ←
A
1401 Chain container P complete set 1 EQ1CI1401 ← ← EQ1DI1401 Plastic container
17 401 Chain container P 1 EQ1CI9401 ← ← EQ1DI9401
18 166 Socket bolt 1 J1BE1-0809028 ← ← J1BE1-0812028 For Chain container
19 226 Lever nut 1 C2BA100-9074 ← ← ← For Chain container
B
1405 Chain container (15) complete set 1 EQ1CI1405 ← ← × Canvas container
17 5405 Chain container (15) assembly 1 EQ1CI5405 ← ← ×
18 166 Socket bolt 1 J1BE1-0809028 ← ← × For Chain container
19 226 Lever nut 1 C2BA100-9074 ← ← × For Chain container
20 1521 Power supply cable 4C assembly 1
ZLZB11CQ1000 ← ← ←
ZLZB11AQ1000 ← ← ←
Cable one size larger than
the standard size
21 521 Power supply cable 4C 1
Z2CU401-0000 ← ← ←
Z2CU402-0000 ← ← ←
Cable one size larger than
the standard size
22 541 Cable support arm 1 ER1BS9541 ← ← ←
23 1542
Cable support 12 assembly
1
E7AX003S2822 ← ← ←
Cable support 14 assembly E4YS005-2822 ← ← ←
Cable one size larger than
the standard size
24 569 Holder A 1 ECP5924AA ← ← ←
25 574 Cable packing 1
ECP6912AA ← ← ←
ECP6914AA ← ← ←
Cable one size larger than
the standard size
26 823 Name plate G 1 E6LE010S9806 ← ← ←
27 542 Machine screw with spring washer 2 J1AP2-6001616 ← ← ← For Cable support arm
28 1557
3 push button cord 5C complete
set
1 ZLD0015W1000 ← ← ←
29 557 Push button cord 5C 1 Z3CA500-0000 ← ← ←
30 1561 3 push button switch assembly 1 SWJ2200AA ← ← ←
31 565 Warning tag PB 1 SWD9013AB ← ← ←
32 566 Tag holder 1 E7SE003S9787 ← ← ←
33 569 Holder A 1 ECP5924AA ← ← ←
34 574 Cable packing 1 ECP6910AA ← ← ←
35 535 Cord support (wire stopper) 1 ER1BS9534 ← ← ←
36 536 Machine screw with spring washer 2 J1AP2-5001212 ← ← ← For Cord support
37 891 Holder B 2 ECP5924AB ← ← ←
38 892 Holder packing 2 ECP5924AQ ← ← ←
39 893 Holder nut 2 ECP5924AD ← ← ←
40 053 Cushion rubber 2 ER1CS9053 ← × ×
