KITO EQ series User Manual

41
Assembling Combining with the Motorized Trolley
1
■
Length of Adjusting Spacer
A
B C
Thick spacer/Fixing spacer (300)/Thick
spacer L/Thin spacer L/Thin spacer
(Unit: mm)
125kg, 250kg, 490kg, 500kg, 1t *
Thick spacer
A 12.5
B 38.4
C 32
Fixing spacer (300)
A 50
B 38.4
C 32
Thick spacer L*
A 12.5
B 45
C 32
Thin spacer L
A 5.5
B 50.8
C 32.8
Thin spacer
A 3.2
B 43
C 32.5
Suspension shaft diameter 31
* Thick spacer L is not necessary for 1t type. Please remove it if it is in.
