Push the sliding direction bar fully to the left or right. The side that
you push this to doesn't matter when the normal head is attached.
The direction is only relevant if the drill head is attached. For the
normal head that creates the up and down motion the direction
that the drive mechanism moves
in is not relevant because either
way the mechanism will still go up
and down. It is important to ensure
that the direction switch is fully
pushed either to the left or right
because if you have it in the mid-
dle the gun will not operate.
On the top of the head you will see an adjustment screw. The
more that this is turned clockwise the more the screw enters the
head. This has the effect of pushing down on the levering probe
more and so the more it pushes it down the less movement there
will be. It is suggested that you start off with less movement and
then gradually unscrew that adjustment screw to create more movement of
the pick/probe as is desired.
You should now be ready to start picking!
