8
OPERATING INSTRUCTIONS
3. AC Receptacles (Fig. 3)
Two AC receptacles are located at the front center
of the charger. One receptacle can supply 120V~,
up to 10Amp for your other devices. If using both
receptacles at the same time, they can supply up to
a TOTAL of 10A for the two receptacles.
If the device draws more than the rated output of
the receptacles (Max. 10A for each receptacle or
Max. 10A for both receptacles,) it will likely trip
the charger. The charger is equipped with a fuse
replace it if the fuse blown.
WARNING
• All maintenance, including fuse replacement,
should only be carried out by a qualied service technician or an authorized service
organization.
4. Wall-mount holes (Fig. 4)
The charger has hanging holes for convenient storage. Install screws in the wall 16 inches
apart. Use screws sufciently strong to hold the combined weight of the charger and battery
pack.
4
3
