Kodiak SXA1900HX, Operating And Maintenance Instructions

SXA MAN 04/05 Page11
 Battery charger (SXB2800HX,SXB4000HX,SXB5500HX(S),SXB7000HX(S) only)
The DC terminal is used only for charging 12 volt batteries. It provides up to
12V-8.3A(100W) of maximum power.
CAUTION: Be sure to make correct connection to the battery.The positive(+)
Battery terminal should be connected to the “red” terminal.
Do not over-charge the battery. Over-charging of a battery can result in
Personal injury due to explosion of battery.
Tee Slot GFCI
Receptacle
4 wire Twist lock
receptacle
NEMA L14-30
Output voltage
selector switch
No Fuse Breaker
Output voltage meter
12 V DC output
Engine ON/OFF
switch
120 volt Twist lock
receptacle
NEMA L5-30
Auto Throttle
switch
“Power On” Indicator
Light
