Kodiak SXA1900HX, Operating And Maintenance Instructions

SXA MAN 04/05 Page9
Check the appliance and/or generator for overloading or
defect, make necessary corrections or repairs before use.
 Dual voltage type (SXB4000HX,SXB5500HX(S),SXB7000HX(S) only)
(a) Select the voltage using the “select” switch in accordance with the
electrical appliance. Refer to table below.
(b) Operate in the same way as single voltage type.
SWITCH
LOWER VOLTAGE RECEPTACLE
HIGHER VOLTAGE RECEPTACLE
110V or 120V
RATED OUTPUT IS AVAILABLE
UNAVAILABLE
110V/220V or
120V/240V
HALF OF RATED OUTPUT IS
AVAILABLE
RATED OUTPUT IS AVAILABLE
4 wire Twist lock
receptacle
NEMA L14-30
Engine ON/OFF
switch
12 V DC output
Output voltage meter
Output voltage
selector switch
No Fuse Breaker
120 volt Twist lock
receptacle
NEMA L5-30
Tee Slot GFCI
Receptacle
Auto Throttle
switch
“Power On” Indicator
Light
