7
Operation
Dual voltage type (SXB4000HX,SXB5500HX(S),SXB7000HX(S) only) continued:
Diagram 7: SXB5500HX Control Panel
Diagram 8: SXB7000HX Control Panel
Tee Slot GFCI Receptacle
120 Volt
Twist Lock
Receptacle
NEMA L5-30R
Auto Throttle
Switch
12V DC
Output
Engine
“ON/OFF”
Switch
Output Voltage
Meter
“Power On”
Indicator
Light
Output voltage
selector switch
4 wire Twist
lock receptacle
NEMA L14-30R
No Fuse Breaker
Tee Slot GFCI Receptacle
120 Volt
Twist Lock
Receptacle
NEMA L5-30R
Auto Throttle
Switch
12V DC
Output
Engine
“ON/OFF”
Switch
Output Voltage
Meter
“Power On”
Indicator
Light
No Fuse
Breaker
4 wire Twist
lock receptacle
NEMA L14-30R
Output voltage
selector switch
