Koenders Superior Windmill - Page 3

3
Item # Quantity
in 12’ set
Quantity
in 20’ set
Description Diagram (not to scale)
1 1 PLASTIC TOWER TOP
2 6 6 CROSS BAR TENSIONER
3 24 5/16" SELF TAPPING SCREWS
4 6 GROUND STAKE CLAMPS
5 3 GROUND STAKE
6 1
SINGLE DIAPHRAM
COMPRESSOR UNIT OR
DOUBLE DIAPHRAM
COMPRESSOR UNIT
7 1 PIVOT POST
8 1 RIM WASHER AND BEARING
9 2 TAIL ARMS
10 2 TAIL FIN
11 12 FAN BLADES
12 12 BLADE BRACES
13 1 DOME
14
1 HUB ASSEMBLY
