English
Size - A5 Size - A5
Installation
Note:
The washing machine is equipped with
power cord and plug and needs sewage and
tap water connection. Make sure before
installation that the wall outlet is at the
desired place of installation.
Consider the dimension (chapter Technical
data) of the product for placing and
installation.
Caution
• Before initial operation the transport
restraints must be removed from the
backside of the unit. Operating the
washing machine with mounted transport
restraints leads to serious damages.
• Keep the transport restraints for later
use. Never transport the device without
correctly mounted transport restraints!
Fig.
1
Loosen the four transport restraints
with a wrench (13 mm) and unscrew
them completely. Insert the 4 supplied
blind plugs in the holes.
Fig.
2
Place the washing machine on an even,
horizontal and steady surface. For
levelling the feet are adjustable and can
be screwed in or out.
• Unscrew the lock nuts with a open-
end wrench (17 mm).
• Turn the feet to the right to screw
them in and to the left to unscrew
them.
• Use a spirit level to check
whether the appliance is leveled.
If the appliance is not standing
horizontally or is tilting the feet
must be adjusted again.
• If the unit is leveled and does not
tilt, tighten the nuts with the open-
end wrench.
Fig.
3
The washing machine must be
connected to a drain.
• The drain hose is already fixed to the
sewage connection. Pull the hose
out of the clamps and unwind it.
• Connect the other end to the drain
pipe (option A or B). Observe the
max. height of the hose end.
Note:
Suitable hose holders are available as
optional accessories.
KWM 71412 KWM 81412_170921_V05_HR.indb 18 21/9/17 1:40 pm
