Kohler Co. 7 1396808-T01-A
INSTALLATION OF REMOTE CONTROLLER /
安装遥控器
Note:
If the wall for installation is made of special material (such as wood
board, density board and etc.), proper fixing methods shall be adopted.
注意：
Note:
The place to install the remote controller shall not be easily splashed
by water.
注意：
Choose a mounting location for the remote holder that is easily accessible
while sitting on the seat.
Drilling two holes with depth larger than 45mm on the wall by drill with a di-
ameter of 6mm in accordance with the position of screw holes on the remote
control holder, and then installs the expansion tube into the holes.
6mm
45mm
Place the installation holder on the fixing hole.
Fix the holder with screws and install it.
Install the screw covers on the screws.
Place the remote controller on the holder.
Expansion pipe
