Faucet Installation (cont.)
A minimum distance of 1-3/4″ (44 mm) is required between the
back of the spout and the wall to allow access to the screw.
Install the Faucet
Determine the mounting hole location.
Drill a hole through the mounting surface according to the
surface manufacturer’s instructions.
Install the stud to the underside of the faucet.
Slide the O-ring over the flexible hoses and stud, then seat the
O-ring in the groove on the underside of the spout.
Insert the spout with flexible hoses and stud through the
mounting hole.
From under the sink, slide the rubber washer and bracket onto
the stud.
Thread the nut onto the stud to secure the faucet to the mounting
surface.
1244026-2-A 4 Kohler Co.
