Configuration Options by Interface
UIC
DTV-UI
Interface Option 1
Interface Option 2
Control
Cable Input
Front of Generator
(Access Panel)
Drain/Spill Pan
Steam
Head
Drip Loop
50' (15.2 m)
Control Cable
Control
Cable Input
Front of Generator
(Access Panel)
Drain/Spill Pan
RS485 Adapter
Temperature
Sensor
Media
Module
Steam Head
2-Way Coupler
1060226-2-E 4 Kohler Co.
