5. Install the Water Supply
All Installations
IMPORTANT! Optional bidet water supply is shown. Do not install
a second water supply unless a bidet seat will be installed.
Install the water supply pipes, following all local codes.
Connect the waste pipe following all applicable local codes.
If using a G 1/2 connection, remove the 1/2″ NTP adapter and
discard.
Installations With a Bidet Seat
Optional: Install the bidet water supply and a quarter turn, 1/2″
NPT supply shut-off.
IMPORTANT! The bidet supply shut-off must extend 3″ (76 mm)
minimum to 4″ (102 mm) maximum from the finished wall to allow
access to the handle. The supply shut-off handle should be no
higher than 5/8″ (16 mm) from the center of the water supply.
Bidet Water Supply
(Optional)
5/8"
(16 mm)
Max
4" (102 mm)
Maximum Clearance
from the Front of
the Finished Wall
1/2" NTP
Adapter
Kohler Co. 11 1246750-2-B
