IMPORTANT INSTRUCTIONS
READ AND SAVE FOR THE
CONSUMER
WARNING: Risk of scalding or other severe injury.
CAUTION: Risk of scalding hazard. This device has been
calibrated at the factory to ensure a safe maximum water
temperature. Any variance in settings or water inlet
conditions from those used during factory calibration may
raise the discharge temperature above the safe limit, and may
present a scalding hazard.
•
Before completing installation, the installer must set the
maximum water temperature setting of this valve to minimize the
risks associated with scalding hazards according to ASTM F 444.
The installer is responsible for adjusting the maximum water
temperature of this valve according to instructions.
This valve meets or exceeds ASME A112.18.1/CSA B125.1 and ASSE
1016/ASME A112.18.1016/CSA B125.16.
If you do not understand any of the temperature adjustment
instructions in this document, in the United States please contact our
Customer Care Center at 1-800-4KOHLER. Outside the U.S., please
contact your distributor.
IMPORTANT NOTICE: Please fill in the blanks on the valve label and
below, in the NOTICE TO HOMEOWNERS box. Retain this guide for
future reference.
•
The valve is calibrated to 104°F (40°C) at the first stop position,
and the maximum temperature limit stop is positioned so the
outlet water temperature does not exceed 120°F (49°C).
•
Factory calibrated inlet conditions are:
Hot and cold water pressure = 43.5 psi (300 kPa)
Hot water supply temperature = 149°F (65°C)
Cold water supply temperature = 59°F (15°C)
•
If inlet conditions differ from those used during factory
calibration, it may be necessary to re-calibrate the valve after
installation. The installer must check the mixed flow
temperature after installation, and adjust the valve as needed
according to the instructions.
1205551-2-C 2 Kohler Co.
