Install the Remote Dock (cont.)
NOTE: There is a wiring schematic on the inside of the docking station. Refer to the schematic when
attaching the wires.
Slide the bare end of the wires into the correct port (as shown) and tighten each screw to secure the
wires in place.
Position the docking station over the installation location.
Connect the base plate of the docking station to the wall using two screws.
Reconnect the cover plate cable to the base.
Snap the cover plate back into place.
Remove the screw and tape from the cover plate and secure the cover plate with the screw to the
base of the docking station.
Kohler Co. 11 1132336-2-D
