3. Install the Support Framing
NOTICE: For proper countertop installation, the top of the sink
must not extend above the top of the cabinet.
Cut two lengths of support framing to extend horizontally along
the inside walls on each side of the cabinet.
Measure and mark the support mounting locations; ensure the
sink rim will sit at or slightly below the top of the cabinet.
Position and level the supports.
TIP: Use clamps to hold the supports in position.
Secure the supports with construction adhesive and screws (not
provided).
Optional Vertical Supports
Cut four lengths of support framing to extend from the bottom of
the horizontal supports to the floor of the cabinet.
Secure the vertical supports with construction adhesive and
screws (not provided).
5/8"
(16 mm)
Optional Vertical
Supports
1217971-2-A 6 Kohler Co.
