⑶When distance measurement is completed, a
short beep sounds, and the measured distance
data (s), vertical angle (ZA), and horizontal angle
(HAR) are displayed.
The result of repetition measurement is displayed：
During average measurement, the distance data is
displayed as S-1, S-2……
Dist. PC -30
PPM 0
3
S 1234.569 m
ZA 89°59′54″
HAR 117°31′50″
STOP
Dist. PC -30
PPM 0
3
S-1 1234.569 m
ZA 89°59′54″
HAR 117°31′50″
STOP
⑷When repeat measurement is performed, press
STOP after displaying the measurement values
to conclude distance measurement and display
the final results of the measurements.
STOP
During average measurement, the average value of
the distance (S-A) is displayed when the designated
number of measurements has been completed.
Dist. PC -30
PPM 0
3
S-A 1234.568 m
ZA 89°59′54″
HAR 117°31′50″
P1
SDIST SHV HSET EDM
☆ The distance and angle which are most recently measured remain stored in the memory until the power
is turned off. It is possible to display the measured values converted into the horizontal distance, height
difference, and the slope distance by pressing SHV. For the display method, see “9.4 Review of Measured
Data.”
☆ If the single measurement mode and N-times= N are selected, measurement automatically stops after
appointed measurements completed.
9.4 Review of Measured Data
· The distance and angle measured most recently are stored in the memory until the power is switched off.
The distance measurement value, vertical angle, horizontal angle, and the XYZ coordinates can be
