Before assembly, the following
tools are required:
1. Protective Eye Wear
2. Flat Head Screwdriver
3. Pliers
1. U-Handle (R244) x 2
2. Wire Opener Inner Shield
(R140) x 2
3. Wire Opener Bracket (R128) x 2
4. Wire Opener (R129) x 2
5. M5 Screw x 8
6. M6 Screw x 4
7. M6 Lock Nut x 2
8. M6 Nut x 4
9. M6 Lock Nut x 8
1
1
2
2 3
3
4
5
9
7
6
8
10
15
11
16 17
12
18
19
13
14
10. Crossbar Bracket (R242) x 2
11.Thumb Screw (R246) &
Washer (R247) x 2
12. Wrench x 1
13. Wire Removal Tool (R062) x 1
14. Crossbar (R241) x 1
15. Upright with Y-Joint (R249) x 2
16. Chrome Upright (R240) x 2
17. Wire (R101) x 62
18. Cone (R127) x 2
19. Wire Mounting Disk (R090) x 2
To Next Page
