Vers. 100919
KBL04 – 15FR/CA/FN:
ESPLOSO/ EXPLODED VIEW
PARTI DI RICAMBIO/ SPARE PARTS
RIF
DESCRIZIONE/ DESCRIPTION
COD.
1
KBL04FR/CA
190004/CA
KBL15FR/CA
190015/CA
2
Compensatore/ Axial compensator
800322
3
Vite/ Screw M3x5 T10 (4)
801003
4
Flangia supporto/ Support plate
251140
5
Vite/ Screw M3x5
200039
6
Bussola guida telescopica/ Telescopic drive bush
251141
7
Permaglide
800334
Cavo/ Cable 5 pin
200063
