Vers. 100919
KBL30-40FR/CA/FN:
ESPLOSO/ EXPLODED VIEW
PARTI DI RICAMBIO/ SPARE PARTS
RIF
DESCRIZIONE/ DESCRIPTION
COD.
1
KBL30FR/CA
190030/CA
KBL40FR/CA
190040/CA
2
Compensatore/ Axial compensator
800322
3
Vite/ Screw M3x5
200039
4
Flangia supporto/ Support plate
251240
5
Vite/ Screw M3x5
200039
6
Bussola guida telescopica/ Telescopic drive bush
251241
7
Permaglide
800334
Cavo/ Cable 5 pin
200063
