PLUTO..CA/N:
ESPLOSO/ EXPLODED VIEW
INGOMBRO/ DRAWING
PARTI DI RICAMBIO/ SPARE PARTS
RIF
DESCRIZIONE/ DESCRIPTION
COD.
1
Connettore/ Connector M 5 pin
201666
2
Coperchio/ Cap
800304
3
Motore/ Motor PL3
231509/3M
Motore/ Motor PL6
231509/6M
Motore/ Motor PL10
231509M
Motore/ Motor PL15
231509/15M
4
Riduttore/ Reduction gears PL3
231510/3M
Riduttore/ Reduction gears PL6
231510/6M
Riduttore/ Reduction gears PL10
231510/M
Riduttore/ Reduction gears PL15
231510/15M
5
Vite/ Screw M3x6 (3)
801002
6
Cannotto alluminio/ Aluminium body
234510
7
Vite brugola/ Screw M3x8 (4)
231508/ZEN
Cavo/ Cable 5 pin 2,5 mt.
200063
