10-2 82E-5 – 98E-5 SERIES
10. ALTERNATOR
10.1 The 40A Alternator for 3D84E and Other Models
As a representative example of alternator, the alternator of 40A is shown in this chapter.
10.1.1 Components
(1) Parts related to the alternator
(2) Alternator components of the disassembly and assembly
