Koncar UKE3020KDCVTM - Page 46

EN - 10
W
D
C2
A
B
C1
H
F
HOB
W
D
C2
A
B
C1
Separator
E
E
H
Separator
F
HOB
• Apply the supplied one-sided self-
adhesive sealing tape all the way
around the lower edge of the cooktop.
Do not stretch the tape.
Self-adhesive
sealing tape
Worktop mounting
bracket
• Screw the 4 worktop mounting brackets
on to the side walls of the appliance.
