USAGE NOTES
Settings - Direction / Height
4 First hold the holder.
4 Then loosen the clamping screw of the prismatic
clamp
4.a Turn the holder in the desired direction (this
4.a process can be used to properly distribute the
4.a weight on the stand).
4.b Adjust the height of the holder on the stand.
Then manually tighten the clamp screw of the
prismatic clamp.
CHECK, MAINTENANCE, CLEANING
To care for the product use a damp cloth and a non-abrasive cleaning agent.
FAULT-FINDING (F) and REPAIR (R)
F: Installation looks like it’s lopsided. B: Tighten the screws on the prismatic clamp and support arm.
F: The stand is lilting to one side. B: Check to ensure that the stand can carry the weight; balance the various weights to ensure
B: that the stand is stable and sturdy.
TECHNICAL DATA
Material
Prismatic clamp, bracket: Steel, powder coating, black
Screws: Steel, galvanized
Handles, caps: Plastic (PA)
Quiver: Polyester material
max. weight Drum Sticks
Dimensions Quiver: ø 90 x 250 mm, prismatic clamp: ø 7-30 mm
Weight 0.22 kg
Packaging 132 x 50 x 225 mm
KÖNIG & MEYER GmbH & Co. KG
Kiesweg 2, 97877 Wertheim, www.k-m.de
16450-000-55 Rev.02 03-80-092-00 11/14
DIMENSIONS (Measurements in mm)
