ISOFIX Insertion Aids
ISOFIX Fastening Points(vehicle)
Headrest
Seat Cover
Shoulder Pads
Shoulder Straps
Harness Buckle
Crotch Pad
Adjustment Button
Adjustment Strap
360° Rotation Adjuster
Seat Reducer
Buckle Tongues
Red Release Button
Belt Guidance
Recline Handle
Base
Shoulder Straps Connector
Headrest Height Adjuster
Top Tether Adjuster
ISOFIX Locking Arms
ISOFIX Buttons
Top Tether Clip
Read the instructions carefully before use and keep for future
