Korg TRITON Le Service Manual

PART CODE PART NAME NOTE Q'TY
454011700
DIN CONNECTOR TCS5073-24-4151 KLM-2386 TRITO
1
464002300
FUSE 125V 2A SB2 TRITON LE88 M.
1
471101030
CONNECTOR TOP SC25-03WS KLM-2386 TRITO
1
471101060
CONNECTOR TOP SC25-06WS KLM-2278/79/80
1
471101060
CONNECTOR TOP SC25-06WS KLM-2386 TRITO
1
471102030
CONNECTOR TOP SJ20-03WX KLM-2278/79/80
1
471102030
CONNECTOR TOP SJ20-03WX KLM-2386 TRITO
1
471102030
CONNECTOR TOP SJ20-03WX KLM-2387 TRITO
1
471102040
CONNECTOR TOP SJ20-04WX KLM-2386 TRITO
1
471102040
CONNECTOR TOP SJ20-04WX KLM-2387 TRITO
1
471102060
CONNECTOR TOP SJ20-06WX KLM-2386 TRITO
1
471102070
CONNECTOR TOP SJ20-07WX KLM-2387 TRITO
1
471102080
CONNECTOR TOP SJ20-08WX KLM-2387 TRITO
1
471102080
CONNECTOR TOP SJ20-08WX KLM-2278/79/80
2
471102080
CONNECTOR TOP SJ20-08WX KLM-2386 TRITO
1
471102120
CONNECTOR TOP SJ20-12WX KLM-2278/79/80
2
471102130
CONNECTOR TOP SJ20-13WX KLM-2386 TRITO
1
471102130
CONNECTOR TOP SJ20-13WX KLM-2278/79/80
1
471102140
CONNECTOR TOP SJ20-14WX KLM-2386 TRITO
1
471102140
CONNECTOR TOP SJ20-14WX KLM-2278/79/80
1
471102150
CONNECTOR TOP SJ20-15WX KLM-2278/79/80
2
472070701
CONNECTOR SIDE S7B-PH-K-S
(
U
)
KLM-2331/32 TR
1
474019600
CONNECTOR 2-215079-0 20P
(
AMP
)
KLM-2387 TRITO
2
474019700
CONNECTOR 76382-404 KLM-2331/32 TR
2
474029500
S.M. CONNECTOR CN015R-3013-0 KLM-2386 TRITO
1
474031000
CONNECTOR B16B-PHDSS KLM-2386 TRITO
1
474033200
SIMM CONNECTOR 404A-072SABA01 KLM-2386 TRITO
2
474033700
CONNECTOR 302A-50PGAS003 KLM-2386 TRITO
1
475002577
HARNESS HNS-2577 TRITON LE88 M.
1
475003049
HARNESS HNS-3049 TRITON LE88 M.
1
475003051
HARNESS HNS-3051 TRITON LE88 M.
1
475003052
HARNESS HNS-3052 TRITON LE88 M.
1
475003054
HARNESS HNS-3054 TRITON LE88 M.
1
475003101
HARNESS HNS-3101 TRITON LE88 M.
1
475003181
HARNESS HNS-3181 TRITON LE88 M.
1
475003182
HARNESS HNS-3182 TRITON LE88 M.
1
475003183
HARNESS HNS-3183 TRITON LE88 M.
1
475003184
HARNESS HNS-3184 TRITON LE88 M.
1
475003185
HARNESS HNS-3185 TRITON LE88 M.
1
475003186
HARNESS HNS-3186 TRITON LE88 M.
1
475003187
HARNESS HNS-3187 TRITON LE88 M.
1
475102941
HARNESS HNS-2941
(
F
)
L=40CM TRITON LE88 M.
2
480010380
DIN JACK YKF51-5041 KLM-2386 TRITO
1
500033200
RUBBER FOOT K-23 TRITON LE88 M.
5
515400100
FUSE HOLDER CNT47-0003A
(
TR
)
KLM-2386 TRITO
2
525001400
FERRITE CORE F5 T 25X12X15 TRITON LE88 M.
1
550018900
X-0180 SPONGE KOC-F40970 TRITON LE88 M.
1

Korg TRITON Le Specifications

General

Polyphony	62 voices
Display	240 x 64 pixel backlit LCD
MIDI	In, Out, Thru
Power Supply	AC adapter (included)
Type	Workstation Keyboard
Keyboard	61 keys
Sound Engine	HI Synthesis
Synthesis Method	PCM
ROM Wave Memory	32 MB
Programs	512 Programs
Drum Kits	24 drum kits
Effects	2 multi-effects processors, 1 master effect, 1 total effect
Sequencer	16-track, 200, 000 notes
Arpeggiator	1 arpeggiator
Storage	SmartMedia card
Outputs	L/MONO, R, Headphones
Floppy Disk Drive	3.5 inch 2DD/2HD
