Korg TRITON Le Service Manual

PART CODE PART NAME NOTE Q'TY
550019400
X-2110 KB FELT 5 KOC-F41031 TRITON LE88 M.
2
550019600
X-0120 KB FELT 6 KOC-F41032 TRITON LE88 M.
1
575019700
LED SPACER LH-5-5 L=5MM KLM-2278/79/80
1
620024600
X-952 POWER SW KNOB E40304-2 TRITON LE88 M.
1
620034600
X-631 SVR KNOB
(
GRAY
)
E40239-6 TRITON LE88 M.
1
620034700
X-610 ENCODER KNOB
(
GRAY
)
E40466 TRITON LE88 M.
1
620043900
KNOB P423-9GF
(
-0180
)
E40519-2 TRITON LE88 M.
4
630034200
X-0180 LCD WINDOW KOC-F40962 TRITON LE88 M.
1
630034300
X-0180 REFLECTION FILM F40967 TRITON LE88 M.
1
630034400
X-0180 DIFFUSION FILM F40968 TRITON LE88 M.
1
630034500
X-0180 BLACK FILM KOC-F40969 TRITON LE88 M.
1
641041172
X-323 JACK PLATE 2 KOC-C40963 KLM-2386 TRITO
1
641041651
X-0180 REAR OP COVER KOC-C4122 TRITON LE88 M.
1
641041666
X-0390/1310 KB BASE C41239-1 TRITON LE88 M.
3
641041671
X-0370 HP ANGLE KOC-C41230 TRITON LE88 M.
1
641041739
X-2110 PENEL KOC-C10240 TRITON LE88 M.
1
641041740
X-2110 COVER ANGLE KOC-C41274 TRITON LE88 M.
5
641041741
X-2110 SIDE CHASSIS L KOC-C203 TRITON LE88 M.
1
641041742
X-2110 SIDE CHASSIS R KOC-C203 TRITON LE88 M.
1
641041743
X-2110 JS SUPPORT KOC-C20386 TRITON LE88 M.
1
641041744
X-2110 HP ANGLE 1 KOC-C30592-1 TRITON LE88 M.
1
641041745
X-2110 HP ANGLE 2 KOC-C30592-2 TRITON LE88 M.
1
641041746
X-2110 SUPPORT CHASSIS KOC-C30 TRITON LE88 M.
1
641041747
X-2110 FRONT BAR KOC-C30590 TRITON LE88 M.
1
641041748
X-2110 PCB BOX KOC-C10241 TRITON LE88 M.
1
641041749
X-2110 OP COVER KOC-C30591 TRITON LE88 M.
1
641041750
X-2110 SIMM COVER KOC-C41273 TRITON LE88 M.
1
644009000
X-8510 GND SPRING
(
K
)
C41167 TRITON LE88 M.
2
645053296
X-2110 SIDE CHASSIS L D30254-1 TRITON LE88 M.
1
645053297
X-2110 SIDE CHASSIS R D30254-2 TRITON LE88 M.
1
645053298
X-2110 BOTTOM KOC-I10082 TRITON LE88 M.
1
646078900
X-0180 KNOB BLOCK A-1 E20211-1 TRITON LE88 M.
1
646079000
X-0180 KNOB BLOCK A-2 E20211-2 TRITON LE88 M.
1
646079100
X-0180 KNOB BLOCK B-1 E10191-1 TRITON LE88 M.
1
646079200
X-0180 KNOB BLOCK B-2 E10191-2 TRITON LE88 M.
1
646079300
X-0180 LIGHT GUIDE HOLDER TRITON LE88 M.
1
646079600
X-0180 LIGHT GUIDE EY1L-GB01K TRITON LE88 M.
1
646079700
X-0180 JOYSTICK ASSY H30214-1 TRITON LE88 M.
1
646084600
X-2110 JS PANEL KOC-E20220 TRITON LE88 M.
1
646084700
X-2110 KEY BLOCK KOC-E30291 TRITON LE88 M.
1
646084800
X-2110 SM FRAME KOC-E20221 TRITON LE88 M.
1

Korg TRITON Le Specifications

General

Polyphony	62 voices
Display	240 x 64 pixel backlit LCD
MIDI	In, Out, Thru
Power Supply	AC adapter (included)
Type	Workstation Keyboard
Keyboard	61 keys
Sound Engine	HI Synthesis
Synthesis Method	PCM
ROM Wave Memory	32 MB
Programs	512 Programs
Drum Kits	24 drum kits
Effects	2 multi-effects processors, 1 master effect, 1 total effect
Sequencer	16-track, 200, 000 notes
Arpeggiator	1 arpeggiator
Storage	SmartMedia card
Outputs	L/MONO, R, Headphones
Floppy Disk Drive	3.5 inch 2DD/2HD
