Defining AV Routing Parameters
Set the KDS-SW2-EN7 AV routing parameters.
To set AV routing parameters:
1. In the Navigation pane, Select Main>AV Routing. The AV Routing page appears (see
Figure 12).
2. Select an input from the drop-down box (HDMI IN1 or USB IN2).
3. Define the following settings:
▪ Channel ID: Set Channel ID and click APPLY.
Channel ID defines the device input ID (1 to 999).
▪ Channel Name: Enter the Stream Name and click APPLY.
Stream name is identical to Host name (see General Device Settings on page 28)
can include up to 24 characters; “-“ and “_” are allowed within the name.
by default, the name is the model name and MAC address connected by “-”.
▪ Volume: Use the slider to
▪ adjust the analog audio output volume (0 to 100%).
Default is 80 (0dB), 100% (12dB) and 0 is mute.
▪ Mute: Mute/unmute all audio outputs (HDMI OUT, AUDIO OUT, and MEDIA ports).
▪ Play/Stop: Start or stop streaming of video, audio, IR, RS-232 and USB signals.
4. View the following streaming parameters: HDCP Encryption, Resolution, Aspect Ratio,
Audio Channels, Audio Rate and Audio Format.
Routing parameters are defined.
Defining Auto Switching
Set KDS-SW2-EN7 auto switching to one of three configurations:
• Last Connected (default) – When a video source input is detected, the device switches
to that latest connected video source to the output.
When the selected video source is disconnected, the device switches to the other video
source automatically.
• Priority – When both HDMI IN 1 and USB IN 2 are connected to video sources, after the
device is powered on, the input port with higher priority is selected.
When the selected video source is disconnected, the device switches to the other (lower
priority) video source automatically.
• Manual – The input is selected manually.
