Kramer VM-51 User Manual

VM-51 - Overview
5
#
Feature
Function
1
OUT BNC connectors
Connects to the video acceptors (up to 5)
2
INPUT BNC connector
Connects to the video source
3
Gain Trimmer
Adjusts the video signal level (using a small screwdriver)
4
EQ. Trimmer
Adjusts the video EQ. (equalization) compensation
5
ON LED
Illuminates when receiving power
6
12V DC
+12V DC connector for powering the unit
