Kramer VP-420

VP-420, VP-421 - Operating the VP-420, VP-421
11
5.2.3 The “OUTPUT” Submenu
The “OUTPUT” submenu allows you to choose the output resolution sent to the
display. Each press of the + or – button cycles through the list of resolutions.
The following table defines the resolutions available on the “OUTPUT” submenu
and how they appear on the display.
Parameter
Appears As
Parameter
Appears As
VGA
640x480
WUXGA
1920x1200
SVGA
800x600
480P
480p
XGA
1024x768
576P
576p
1280x800
1280x800
720P50
720p @50Hz
SXGA
1280x1024
720P60
720p @60Hz
UXGA
1600x1200
1080P50
1080p @50Hz
WXGA
1366x768
1080P60
1080p @60Hz
SXGA+
1400x1050
1080p (RGBHV) (appears
in the Menu as 1080PRGB)
1920x1080
WXGA+
1440x900
1080I50
1080i @50Hz
WSXGA
1680x1050
1080I60
1080i @60Hz
5.2.4 The “OSD” Submenu
The “OSD” submenu allows you to adjust the location of the OSD, the length of
time it is displayed, and the darkness of its background.
Parameter
Function
Range
Default
H-POSITION
Adjusts the horizontal position of the OSD on
the screen
0–100
50
V-POSITION
Adjusts the vertical position of the OSD on the
screen
0–100
50
TIMER
Adjusts the length of time in seconds the OSD
appears on the screen
0–100
10
BACKGROUND
Adjusts the shade of the OSD background from
black to transparent
0–8
4
EXIT
Select to exit to the Main Menu
